| Model No. | Pro440C | Pro440C-HD | Pro440K-HD | Pro440D-HD |
| Product Series | Standard Series | Pro Series |
| Maximum Imaging Width | 436mm |
| Printing Method | Four Color Double-Sided (Standard Definition) | Four Color Double-Sided (High Definition) | Monochrome Double-Sided (High Definition) | Two Tone Double-Sided (High Definition) |
| Front and Back Overprint Accuracy | ±0.2mm |
| High Speed Mode | 600dpi |
| Production Mode | 800dpi |
| Fine Mode | 1200dpi |
| Nuzzle | 600dpi Industrial SD Inkjet Nozzle | 1200dpi Industrial HD Inkjet Nozzle | 1200dpi Industrial HD Inkjet Nozzle |
| Ink | Pingment InkJet Ink |
| Ink Color | CMYK | CMYK | BK | K＋N* |
| Max. Printing Speed | 45m/min** | 90m/min** | 120m/min** | 90m/min** |
| Operation Interface | Intelligent Operation Interface |
| Production Software | Standard Configuration |
| Rip Software | High Speed RIP（Supported Standard PDF） |
| Typesetting Software | Intelligent Composition Software |
| Color Management Method | ICC Color International Standard | Linear Color Management |
| Text Process | Processing Text Based on Word Library |
| Feed mode | Roll Material |
| Maximum Roll Diameter | 1270mm |
| Width Range Paper roll | 100mm-460mm |
| Tension control | Automatic Constant Tension Control |
| Paper type | Offset Paper, Writing Paper, Digital Paper, News Paper, etc. |
| Paper weight | 50-120gsm |
| Other functions | Independent Unwinding, Constant Tension, Correction, Double-Sided Tracking |
| Independent Buffering | Ultra Long Independent Buffer |
| Cut Method | Splitting of the Middle Blade, Breaking of the Horizontal Blade |
| Stacking Method | Misplaced Stacking of Volumes |
| Paper Stack Width | 460mm |
| Paper pile length | 140mm-660mm |
| Ink level detection | Segmented Ink Volume Detection, Real-Time Detection |
| Ink Supply Method | Intelligent Constant Pressure Ink Supply, Segmented Ink Supply |
| Drying Method | IR Dry, Hot Air Drying(Automatic Adjustment with Speed) |
| Liquid Cooling System | Fully Automatic Constant Temperature System |
| Quality Monitoring System | Quality Online Monitoring System (Optional) |
| Host | Three Phase Five Wire 380V, 28KW | Three Phase Five Wire 380V, 30KW | Three Phase Five Wire 380V, 28KW |
| Drying System | Three Phase Five Wire 380V, 68KW | Three Phase Five Wire 380V, 62KW | Three Phase Five Wire 380V, 68KW |
| Ambient Temperature | Best Working Range: 25 ℃± 3 ℃ |
| Ambient Humidity | Best Working Range: 40% -70% RH without Condensation |
| Equipment Size | L11250mm×W2450mm×H2250mm*** | L12400mm×W4250mm×H2650mm*** | L11250mm×W2450mm×H2250mm |
| Weight | 12T（The Ground Bearing Capacity is 1T/㎡） | 14T（The Ground Bearing Capacity is 1T/㎡） | 12T（The Ground Bearing Capacity is 1T/㎡） |
| * | Common Dual Colors are K＋C、K＋R，Customizable Spot Color Ink |
| ** | The Printing Speed will Vary with the Cutting Size and Paper Weight |
| *** | This is the Main Machine Size and the Equipment Installation Adopts a Distributed Layout. The actual Size is Subject to the Site Manual. |
